Excelon Plus 84 series relief valve: exhausts excess pressure in the air line, 0.3…10 bar setting, G3/8, inlet pressure up to 20 bar. Installs in-line or modularly with other Excelon Plus units.
Specifications
- Connection: G3/8
- Operating temperature: -34…80 °C
- Max inlet pressure: 20 bar
- Outlet pressure adjustment: 0.3…10 bar
- Gauge port: Rc1/8
- Bonnet material: Aluminium alloy
- Adjusting knob: Acetal
- Medium: Compressed air
- Body material: Aluminium alloy
- Elastomers: Chloroprene rubber (CR)
